MAXI — M is ideal for heat accumulation in commercial installations, for instance from other
models in the MAXI series (MS/MX/MC/MGC),or directly from an external energy source by way
of plate heat exchangers (not included.) Installation kits for cold water inlet with shut-off valve,
hot water outlet with mixing valve, plate heat exchanger with pumps (TURBOSYSTEM) and piping for connecting multiple units has been custom-made to fit directly on the MAXI series.
The commercial cylinders in the MAXI series have shown class-leading operational durability for
commercial hot water systems through the last 50 years.
WHY CHOOSE MAXI?
Advantages
Components
 |  |  | ||
| Specifications | UNIT | M 400 | M 600 | M 1000 |
|---|---|---|---|---|
| Identification | ||||
| Product no. | OSO | 1 1 009 866 | 1 1 003 358 | 1 1 003 353 |
| Product name | M 400 | M 600 | M 1000 | |
| Usage | N/A | N/A | N/A | |
| Placement | Floor | Floor | Floor | |
| Dimensions | ||||
| Diameter — ⌀ | mm | 595 | 800 | 1000 |
| Height - H | mm | 2180 | 2030 | 2120 |
| Weight | kg | 78 | 97 | 176 |
| Packaging | mm | 595 × 595 × 2240 | 800 × 800 × 2000 | 1020 × 1020 × 2200 |
| Freight volume | dm3 | 0.81 | 1.96 | 3.07 |
| Technical/ErP information | ||||
| Capacity | persons | N/A | N/A | N/A |
| Capacity 40°C | L | N/A | N/A | N/A |
| Volume | L | 376 | 570 | 885 |
| Heat-up time ΔT 65°C | hours | N/A | N/A | N/A |
| Thermostat set point | °C | N/A | N/A | N/A |
| Heat loss-EN 12897 | watt | 89 | N/A | N/A |
| AEC (energy consumption) | kW/year | N/A | N/A | N/A |
| Energy efficiency | % | N/A | N/A | N/A |
| Tapping profile | 3XS–XXL | N/A | N/A | N/A |
| Energy rating | A+–F | C | N/A | N/A |
MORE HOT WATER
Substantially higher temperature (70°C+), highly efficient mixing valve (no scolding), minimal heat loss and optimal design features gives up to 20 % more hot water and class leading capacity.
PRO INSULATION
The use of NANOPUR™ with insulation values far surpassing Pentane, often in combination with VACUUM panels, ensures minimum heat loss and class leading energy efficiency.
STRONGER
EVERLAST™ titanium alloyed stainless steel in combination with OSO’s unique ULTRAWELD™ system and state-of-the-art passivation process equals class leading corrosion resistance.
LIGHTER
EVERLAST™ titanium alloyed, high tensile strength, stainless steel equals lower weight and efficient use of resources. OSO products are more than 40 % lighter than enameled products.
BUILT TO LAST
INCOTEC™ el. immersion heaters with ultra high-grade Incoloy 825 stainless, DZR brass, zinc-free soldering and carefully calculated surface loads results in maximum durability in hard water.
Over 85 years OSO Hotwater has earned the trust from suppliers, co-workers and customers. We are still going to earn, and manage, this trust in an exceptionally good way, and value the opinion of our partners.
